Specifications


Code No.VA-001
Coil voltageAC230V /AC220V / AC110V
Voltage range85%~110%
Suitable RefrigerantR12 R22 R134A R502A R600A etc.
Medium temperature-20 °C~120°C
Working Ambient (°C) - 20°C~55°C
Maximum working pressure3.0Mpa
Interior Leak≤ 300mL/min
Life100,000 times
Temperature riseLess than 65
Flow rate≥45~371L/min
O/D connection sizeΦ6.35~Φ8 mm

General

 Used for automatic control and the protect circle of   air-conditioner,dehumidifier, ice maker and some other refrigeration systems.
