Specifications



Code No.	VA-002
Rated voltage	DC12V ±10%
Insulation resistance	above 100MΩ
Driving current	0.25A per Phase
Excitation form	1~2 phase excitation ( 30-90 pulse ), single phase driving
Coil insulation class	E
Refrigerant	R22 R407C R410a & etc.
Working Ambient (°C)	-30°C~+60°C
Medium temperature	-30°C~+70°C
Humidity	Less than 95%RH
Working pressure	0~2.26MPa
Full stoke pulse	500
On-valve converse pressure	1.47MPa(mini)
On-valve pulse	32±20
Life	100,000 times
Temperature rise	Less than 55°C
Nominal capacity	≤5.25kw
Valve port size	1.6~2.4mm
Flow rate	≥27~70 NL/min 500pulse
Maximum working pressure	3.0~4.2 Mpa

General

 Used for frequency conversion air condition to realize the automatic controlling of refrigerant flow rate , thus to make air conditioning system to work in the best situation and realize fast freezing , temperature precision controlling and electric saving .
